Description
Schneider Actassi Cat6 UTP Patch Cord 1 Meter
| range | Actassi | |
|---|---|---|
| product | Patch cord | |
| colour | Blue | |
| cable shielding type | UTP |
| rated voltage | 150 V AC | |
|---|---|---|
| [In] rated current | 1.5 A | |
| insulation resistance | 500 MOhm | |
| cable length (customisable value in configurator) | 0…1 m | |
| communication network category | 6 | |
| contacts material | Phosphor bronze with 50 micro-inches gold over 100 micro-inches nickel | |
| contact resistance | 10 mOhm | |
| AWG | AWG 24 | |
| attenuation | Guaranteed: 0.1 dB | |
| far end crosstalk [FEXT] | 49.8 dB | |
| power sum far end crosstalk [PSFEXT] | 46.9 dB | |
| number of matings | >= 1000 cycles | |
| targeted region | Asia Pacific |
| flame retardance | CM | |
|---|---|---|
| standards | IEC 60603-7 ISO/IEC 11801 2nd edition AS/NZS 3080:2003 TIA/EIA-568-B FCC part 68 subpart F |
| Sustainable offer status | Green Premium product | |
|---|---|---|
| RoHS (date code: YYWW) | Compliant – since 0852 – Schneider Electric declaration of conformity Schneider Electric declaration of conformity | |
| REACh | ||
| Product environmental profile | Available |
