Huawei S310-24P4S 24x GE 10/100/1000 Base-T PoE+ 4 SFP 19″ mount 10G support Managed L3

L2 Smart Switch, managed by the web
24 x GE 10/100/1000 Base-T PoE+, 4 SFP ports
19 inch mount
Built-in power supply
PoE budget: 400W
VLAN, QoS, IGMP snooping

Description

  • Specifications:
Dimensions without packaging (H x W x D) [mm(in.)] Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.)
Dimensions with packaging (H x W x D) [mm(in.)] 90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.)
Chassis height [U] 1 U
Chassis material Metal
Weight without packaging [kg(lb)] 2.92 kg (6.44 lb)
Weight with packaging [kg(lb)] 3.79 kg (8.36 lb)
Typical power consumption [W] 40.07 W
Maximum power consumption [W] •Without PoE: 47.1 W •Full PoE load: 491.66 W (PoE: 400 W)
Static power consumption [W] 30.82 W
Number of fans modules 2
Uplink ports 4 x GE SFP ports
Downlink ports 24 x 10/100/1000BASE-T ports (400 W, PoE+)
Long-term operating temperature [°C(°F)] -5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.)
Restriction on the operating temperature variation rate [°C(°F)] When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Devices cannot start when the temperature is lower than 0°C (32°F).
Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F)
Long-term operating relative humidity [RH] 5% RH to 95% RH (non-condensing)
Long-term operating altitude [m(ft.)] 0–5000 m (0–16404 ft.)
Storage altitude [m(ft.)] 0-5000 m (0-16404 ft.)
Power supply mode AC built-in
Rated input voltage [V] •AC input: 100 V AC to 240 V AC, 50/60 Hz •High-voltage DC input: 240 V DC
Input voltage range [V] •AC input: 90 V AC to 290 V AC; 45 Hz to 65 Hz •High-voltage DC input: 190 V DC to 290 V DC
Console port RJ45
Service port surge protection [kV] Common mode: ±7 kV
Power supply surge protection [kV] Differential mode: ±6 kV; common mode: ±6 kV
PoE Supported
